Product Description
Egyptian Gypsum Raw is one of the best purities in the world

Price of product ( USD price or FOB price) :
USD 28 - 35 USD per MT in Container
USD 17 - 21 USD IN bulk vessels"
CIF prices are subject to date and availability of equipment and vessels

Product origin :
EGYPT

Key Specifications/Special Features :
CaSo4 2H2O: 97.43%
So3: 45.38%
Cao: 31.7%
L.O.I: 22.05%
Whiteness: >92%

Minimum Order Size and Packgaing details :
MOQ: 10 containers (270MT) as a trial order free in containers or jumbo bags
10000 MT in bulk vessels

Gypsum is a soft sulfate mineral composed of calcium sulfate dihydrate, with the chemical formula CaSO4.2H2O. It is widely mined and is used as a fertilizer, and as the main constituent in many forms of plaster, blackboard chalk and wallboard.
GS can Supply and Export Raw material of Gypsum, in several forms Lumps or Powder as the required Micron size with high quality of and purity (94% CaSO4), where it is used for many applications and many industries, and by any quantities, packages and sizes

Gypsum is a very soft sulfate mineral composed of calcium sulfate dihydrate, with the chemical formula CaSO4·2H2O. It is found in alabaster.
there is other analysis as customer need
uses:
1- calcinated gypsum is about 95 % of gypsum uses that we heat the gypsum to 130 degree which remove water and become hemi hydrated gypsum that called plaster of paris, it used in wall plaster, wall lining, plaster board, wall board, tiles for ceikings, partitions. Thermal isolation, regulator to moisture measurements.
2- add Uncalcined gypsum crushed from 3 to 6 % to produce Portland cement so solidification speed become low.
3- gypsum contain 15-20 % sulfur produce ammonium sulfate which act as natural fertilizer.
4- glass industry to easily remove the gases.
5- fine gypsum use in resin industry, paper filler, in soil used in drilling petroleum well.
• by heating to 1093 degree, calcium sulfide form which produce sulfuric acid and lime.
• A binder in fast-dry tennis court clay.
• Plaster of Paris (surgical splints; casting moulds; modeling).
• A wood substitute in the ancient world; for example, when wood became scarce due to deforestation on Bronze Age Crete, gypsum was employed in building construction at locations where wood was previously used.[19]
• A tofu (soy bean curd) coagulant, making it ultimately a major source of dietary calcium, especially in Asian cultures which traditionally use few dairy products.
• Adding hardness to water used for homebrewing.
• A component of Portland cement used to prevent flash setting of concrete.
• Soil/water potential monitoring (soil moisture tension).
• A common ingredient in making mead.
• In the medieval period it was mixed, by scribes and illuminators, with lead carbonate (powdered white lead) to make gesso which was applied to illuminated letters and gilded with gold in illuminated manuscripts.
• In foot creams, shampoos and many other hair products.
• Impression plasters in dentistry

Hyboard is a new and innovative panel engineered and introduced to face the most stringent and challenging construction demands.
This panel is comprised of a ber cement external skin laminated to gypsum to form a robust and durable single piece composite. It is abuse resistant, impact resistant, moisture resistant, and re resistant.
Advantages:
Customizable Gboard and Cboard
combinations that are suitable for any performance requirement
Hyboard is used in areas where high technical performance is required, such as fire rating, abuse resistance, moisture resistance, and sound attenuation.
Surface Finishing:
Painted (water or oil base paint)
Cladding (wallpaper, vinyl, wood
Joint filling with Ccoat Multi Purpose Joint Compound
Edge Types:
Squared edge
Tapered edge
Standards:
ASTM C1396
ASTM C518
ASTM C473
Dimensions:
Width 1200mm,1220mm
Length 2000mm, 2400mm, 2440mm, - 2500mm, 3000mm
Thicknesses 12.5mm, (3.5 mm Cboard & 9 mm Gboard

Gboar RockShield is a noncombustible, waterproof, and mold resistant gypsum board wrapped by glass mat sheathing on the long edges, and front and back faces providing additional reinforcement and protection against weathering. Gboard�® Rockshield is used as a substrate to exterior cladding material such as marble, tiles, brick veneer, clapboard, wood shingles and more. It can withstand heavy wind, rain, and high temperatures.
Advantages
A gypsum board most suitable for outdoor applications
Can withstand weather changes only if properly sheathed
A thermally balanced with low water absorption

Surface Finishing
Multiple finishing options: Painted (Water or oil bas paint)
Wallpaper, vinyl,wood
Joint fillingWith Gcoat All Purpose Joint Compound

Edge Types
Squared edge
Tapered Edge

Standards
ASTM C1396
ASTM C473
ASTM C518
ASTM C1178

Dimensions
Width: 1200mm, 1220mm
Length: 2000mm, 2400mm, 2440mm, 2500mm, 3000mm
Thickness: 9.5mm, 12.5mm, 15.9mm, 18mm

Gboard Echo is a perforated gypsum board with a laminated acoustical eece to its back side. Its core is produced from non-combustible material and offers mechanical stability, which make the board suitable for screw-fastening to drywall framing. Gboard Echo provides excellent sound absorption for suspended ceiling applications or any other application that requires high NRC (Noise Reduction Coefficient) values.
Advantages
A lightweight accoustical fleece that absorbs sound laminated to its backside
High NRC values: up to 0.8
Various perforation types suitable for all applications

Surface Finishing
Multiple finishing options: Painted (Water or oil bas paint)
Wallpaper, vinyl,wood
Joint fillingWith Gcoat All Purpose Joint Compound

Edge Types
Squared edge
Tapered Edge

Standards
ASTM C1396
ASTM C473
ASTM E 84
ASTM C423

Dimensions
Width: 1200mm, 1220mm
Length: 2000mm, 2400mm, 2440mm, 2500mm, 3000mm
Thickness: 8mm, 9.5mm, 12.5mm, 15mm, 15.9mm, 18mm

Gboard Deciloc is a complete sound barrier. Due to its high density and high ber content, when installed in a partition system, ceiling or dry lining system, sound transmission from one area to another is practically eliminated. Gboard�® Deciloc STC rating is designed to reach a sound attenuation up to 75 dB within the system. Gboard Deciloc is used in loud spaces to eliminate sound transmission to neighboring areas. It can be installed around generators and technical rooms, office spaces, hospitals, meeting rooms, cinemas, theaters and large commercial areas where separation is needed.
Advantages
Noise reduction up to 75 Db
Ideal to block sound inside of a space and eliminating its transmission to nearby rooms

Surface Finishing
Multiple finishing options: Painted (Water or oil bas paint)
Wallpaper, vinyl,wood
Joint fillingWith Gcoatâ All Purpose Joint Compound

Edge Types
Squared edge
Tapered Edge


Standards
ASTM C1396
ASTM C473
ASTM C518

Dimensions
Width: 1200mm, 1220mm
Length: 2000mm, 2400mm, 2440mm, 2500mm, 3000mm
Thickness: 8mm, 9.5mm, 12.5mm, 15mm, 15.9mm, 18mm

Gboard FR is a fire-resistant gypsum board reinforced with fiberglass. The fiberglass acts as a retardant and protection to the board, improving the performance of the system when exposed to re. Gboard FR has a pink color paper face. Gboard FR is used in indoor areas such as internal walls and ceiling applications where improved re protection is needed. All materials are certi�ed based on ASTM and EN standards and tested in approved laboratories.
Advantages
Reinforced with fiberglass that improves the performance of the system when exposed to fire
Used in indoor areas as fire protection limiting its spread and growth

Surface Finishing
Multiple finishing options: Painted (Water or oil bas paint)
Wallpaper, vinyl,wood
Joint fillingWith Gcoat All Purpose Joint Compound

Edge Types
Squared edge
Tapered Edge

Standards
ASTM C 1396
ASTM C473
ASMT C518
ASTM E84
EN 520

Dimensions
Width: 1200mm, 1220mm
Length: 2000mm, 2400mm, 2440mm, 2500mm, 3000mm
Thickness: 8mm, 9.5mm, 12.5mm, 15mm, 15.9mm, 18mm

Gboard MR H3 is a moisture resistant board with silicon oil in the core having an average percentage, between 10 and 25 %, of water absorption. The oil acts as a water repellent rendering the core more resistant to moisture. Gboard�® MR H3 is the perfect suit for areas of high humidity. Gboar MR H3 is composed of the best quality gypsum, non-toxic minerals, and moisture repellent additives which suit health conditions. All materials are certiï¬?ed based on ASTM and EN standards and tested in approved laboratories.
Advantages
The perfect suit for humid areas
Moisture resistant board with a percentage of water absorption between 10 to 25%
Convenient backer for showers and bath areas

Surface Finishing
Multiple finishing options: Painted (Water or oil bas paint)
Wallpaper, vinyl,woodâ?¦
Joint fillingWith Gcoatâ?¢All Purpose Joint Compound

Edge Types
Squared edge
Tapered Edge

Standards
ASTM C 1396
ASTM C473
ASTM C518
EN 520

Dimensions
Width: 1200mm, 1220mm
Length: 2000mm, 2400mm, 2440mm, 2500mm, 3000mm
Thickness: 8mm, 9.5mm, 12.5mm, 15mm, 15.9mm, 18mm

Gboard MR H2 is a moisture resistant board having a reasonable percentage, between 5 to 10 %, of water absorption. The silicon oil in its core acts as a water repellent rendering it more resistant to moisture. Gboard�® MR H2 is the perfect suit for areas of high humidity. Gboard�® MR H2 is composed of the best quality gypsum, non-toxic minerals, and moisture repellent additives which suit health conditions. All materials are certified based on ASTM and EN standards and tested in approved laboratories.
Advantages
The perfect suit for areas with high humidity.
Moisture resistant board with a percentage of water absorption between 5 to 10%.
Ideal for toilets, humid areas, reception areas, meeting rooms, cafeterias, showrooms, office buildings, malls, and shops.

Surface Finishing
Multiple finishing options: Painted (Water or oil bas paint).
Wallpaper, vinyl, woodâ?¦
Joint filling with Gcoatâ?¢ All Purpose Joint Compound.

Edge Types
Squared edge
Tapered Edge

Standards
ASTM C 1396
ASTM C473
ASTM C518
EN 520

Dimensions
Width: 1200mm, 1220mm
Length: 2000mm, 2400mm, 2440mm, 2500mm, 3000mm
Thickness: 8mm, 9.5mm, 12.5mm, 15mm, 15.9mm, 18mm

Gboard RG is a regular plasterboard ideal for general drywall and ceiling applications. It is a flexible gypsum board as it can accommodate any indoor architectural design. It is composed of the best quality gypsum, extracted straight from our quarries, and processed using the best ecological practices. All materials are certified based on ASTM and EN standards and tested in approved laboratories.
Advantages
Composed of the best quality gypsum
Ideal for standard interior installation in commercial or residential buildings
A lightweight alternative

Surface Finishing
Multiple finishing options: Painted (Water or oil bas paint)
Wallpaper, vinyl,woodâ?¦
Joint fillingWith Gcoatâ?¢All Purpose Joint Compound

Edge Types
Squared edge
Tapered Edge

Standards
ASTM C 1396
ASTM C 473
ASTM C 518

Dimensions
Width: 1200mm, 1220mm
Length: 2000mm, 2400mm, 2440mm, 2500mm, 3000mm
Thickness: 8mm, 9.5mm, 12.5mm, 15mm, 15.9mm, 18mm

Gboard for gypsum board all types of Regular, fire resistant and moisture resistant

Gboard for gypsum board all types of Regular, fire resistant and moisture resistant

Gtiles Sanitile are hygienic gypsum ceiling tiles free of any banned substances and meet all international health requirements. They are embedded with anti-bacterial properties to create a healthy environment making them an ideal solution for hospitals, operation rooms, nurseries, and more. Combined with a mix of anti-bacterial additives at the core, as well as on the surface and back of the tiles, Gtiles Sanitile are microbe and mold resistant.

Advantages:
Ideal for application in all healthcare facilities
Creating a healthy anti-bacterial environment all while being mold and moisture resistant.

Surface Finishing:
Painted gypsum tile (water or oil base paint)
600 x 600 mm False ceiling grid

Edge Types:
Squared edge

Standards:
ASTM C1396
ASTM D2486
ASTM D4828
ASTM E84

Dimensions:
Width 595 mm, 600 mm
Length 595 mm, 600 mm, 1200 mm
Thickness: 9.5mm, 12.5mm

Gtiles Echo are perforated gypsum tiles that offer virtually endless design possibilities for acoustic ceilings. This solution strikes a perfect balance between functionality and aesthetics and meets the highest requirements for acoustic performance. The excellent quality of the round and square perforations guarantees a highly aesthetic finished ceiling surface. The tiles are laminated with an acoustical fleece on the back that acts as a sound wave diffuser therefore providing comfortable conditions by reducing reverberations. Gtilesâ?¢ Echo are applicable in areas with acoustic requirements such as hospitals, schools, cinemas, and theatres.

Advantages:
An innovative tile that improves air quality by keeping formaldehyde out of the air
Improves sound quality by reducing the echo inside of a room or hall
Is offered in multiple designs that can be painted.

Surface Finishing:
Perforated painted gypsum tile (water or oil base paint)
PVC laminated surface
600 x 600 mm False ceiling grid

Edge Types:
Squared edge
Standards
ASTM C1396
ASTM C 423
ASTM E84

Dimensions:
Width 595 mm, 600 mm, 605 mm
Length 595 mm, 600 mm, 1200mm
Thickness: 12.5mm

Gtiles PVC are made of gypsum, free of any banned substance, and meet all international health requirements. They are highly durable and provide thermal stability for closed areas. Since these tiles are PVC laminated, they are available in different designed finishes, eliminating the need for paint. All tiles have aluminum foil on the back providing a protective layer from vapor with thermal insulation properties.

Advantages:
Gypsum based PVC laminated tiles that are easy to handle, install, and repair
Multiple designs and textures fit for commercial and residential projects
Reflective tiles leading to decrea

Surface Finishing:
PVC Laminated

Edge Types:
Squared edge

Standards:
ASTM C1396
EN ISO 12572
ASTM E84

Dimensions:
Width 595 mm, 600 mm, 605 mm
Length 595 mm, 600 mm, 1200mm, 1215 mm
Thickness: 7mm, 8mm, 9.5mm, 12.5mm

Cboard WP is a waterproof fiber cement board offering superior performance, easy installation, and unparalleled tile adhesion. This technology helps protect tile installations and wall cavities from water penetrations, eliminating the need to apply waterproof coating across the entire surface area of your wall project.

It is used for rain screens in external faade cladding and high technical areas. External and internal applications in all Cboard systems.

Advantages:
A superior waterproof performance
Ideal as a rainscreen for extrernal fa�§ade cladding.

Surface Finishing:
Multiple finishing options:

Painted (Water or oil bas paint)
Wallpaper, vinyl,wood
Joint filling with Ccoat Multipurpose Joint Compound

Edge Types:
Squared edge
Tapered Edge

Standards:
ASTM C1186
ASTM E84
ASTM C518

Dimensions:
Width 1200mm 1220mm
Length 2400mm, 3000mm
Thickness: 4.5mm, 6mm, 8mm, 9mm, 10mm, 12mm, 16mm, 18mm, 20mm

Cboard RG is composed of Portland cement, high purity silica sand, reinforcing pulp recycled in our facilities and additives for water, and fire resistance properties.
Cboard RG is a state-of-the-art asbestos free, highly durable and practical board used in many finishing applications; partition walls, dry linings, suspended ceilings, flooring, and external cladding. Cboar RG is impact resistant, durable and requires low maintenance.
All materials are certified based on ASTM and EN standards and tested in approved laboratories.

Advantages
A solidly light regular fiber cement board ideal for indoor applications.

Surface Finishing:
Multiple finishing options:

Painted (Water or oil bas paint)
Wallpaper, vinyl,woodâ?¦
Joint filling with Ccoat Multipurpose Joint Compound

Edge Types:
Squared edge
Tapered Edge

Standards:
ASTM C1186
ASTM E84
ASTM C518

Dimensions:
Width 1200mm 1220mm
Length 2400mm, 3000mm
Thickness: 4.5mm, 6mm, 8mm, 9mm, 10mm, 12mm, 16mm, 18mm, 20mm

Cboard RG is composed of Portland cement, high purity silica sand, reinforcing pulp recycled in our facilities and additives for water, and fire resistance properties. Cboard�® RG is a state-of-the-art asbestos free, highly durable and practical board used in many finishing applications; partition walls, dry linings, suspended ceilings, flooring, and external cladding. Cboard RG is impact resistant, durable and requires low maintenance. All materials are certified based on ASTM and EN standards and tested in approved laboratories.

Advantages
A solidly light regular fiber cement board ideal for indoor applications.

Surface Finishing:
Multiple finishing options
Painted (Water or oil bas paint)
Wallpaper, vinyl,wood
Joint filling with Ccoat Multipurpose Joint Compound

Edge Types:
Squared edge
Tapered Edge

Standards:
ASTM C1186
ASTM E84
ASTM C518

Dimensions:
Width 1200mm 1220mm;
Length 2400mm, 3000mm
Thickness: 4.5mm, 6mm, 8mm, 9mm, 10mm, 12mm, 16mm, 18mm, 20mm

Gboard Core is manufactured with a thick type X fire-resistant gypsum core. It has enhanced moisture, mold, sound, and impact resistance properties and is used in shaft wall systems, and stairwells where high performance is required to provide enhanced safety for building occupants. Gboard Core system is based on a range of special metal profiles, mainly the Gframe CH-stud to guarantee high performance, stability, ease of installation, and maintenance.
Advantages
Ideal installation in elevators, stairs, and vertical shafts

Edge Types
Squared edge

Standards
ASTM C1396
ASTM C473
ASTM E84
ASTM E119

Dimensions
Width: 600 mm, 610 mm
Thickness: 25.0 mm
Length: 3000 mm
