24v 200Ah lithium battery pack with smart BMS
Cell: lifepo4
Discharge current: 120A
Weight 50.0Kg ±3.0Kg
Size L750mm*W160mm*H400mm
Lifespan: more than 2000 cycles
Communication protocol: RS485, RS232, CAN
Item: 8S60Ah-PC05-A
BMS: with Smart BMS
Nominal Voltage: 24V
Nominal Capacity: 60Ah
Charge Current: 50A
Discharge Current: 60A
Internal Resistance: 40m�©
Life Cycle : more than 2000 cycles
Communication: RS485&RS232
Weight: about 16Kg
Dimension : L310mm*W220mm*H220
Item: 8S60Ah-PC06-A
Charge Current: 120A
Discharge Current: 120A
Life Cycle: 2000 cycles
Communication: RS485&RS232
Weight: 20.0Kg 3.0Kg
Dimension :L330mm W237mm H200
Item: 8S100Ah-PC01-A
BMS: with Smart BMS
Nominal Voltage: 24V
Nominal Capacity:100Ah
Charge Current: 50A
Discharge Current: 100A
Instantaneous Discharge Current:150A
Internal Resistance: less than 150m�?�©
Life Cycle:more than 2000 cycles
Communication: RS485&RS232
Weight: about 20Kg
Dimension : L400mm*W200mm*H170mm
Item: 8S100Ah-PC01-A
BMS: with Smart BMS
Nominal Voltage: 24V
Nominal Capacity: 100Ah
Charge Current: 50A
Discharge Current: 100A
Instantaneous Discharge Current :150A
Internal Resistance: less than150m
Life Cycle: more than 2000 cycles
Communication: RS485&RS232
Weight: about 20Kg
Dimension : L400mm*W200mm*H170mm
Item: 8S120Ah-PC01-A
BMS: with Smart BMS
Nominal Voltage: 24V
Nominal Capacity:120Ah
Charge Current: 60A
Discharge Current: 120A
Internal Resistance: less than 150m
Life Cycle: more than 2000 cycles
Communication: RS485&RS232
Weight: about 31.0Kg
Dimension : L490mm*W190mm*H230
Item: 7S30Ah-PC03-A
BMS: with Smart BMS
Nominal Voltage: 24V
Nominal Capacity: 30Ah
Charge Current: 15A
Discharge Current: 30A
Instantaneous Discharge Current: 15A
Internal Resistance: less than 100m�?�©
Life Cycle: more than 800 cycles
Communication: RS485&RS232
Weight: about 6.0Kg
Dimension : L160mm*W160mm*H155mm
Item: 6S10Ah-PC01-A
BMS: with Smart BMS
Nominal Voltage: 24V
Nominal Capacity: 10Ah
Charge Current: 10A
Discharge Current:15A
Instantaneous Discharge Current:20A
Internal Resistance: less than100m�©
Life Cycle more than 800 cycles
Communication: RS485&RS232
Weight: about 2.0Kg
Dimension : L140mm*W130mm*H60mm
Item: 15S86Ah-PC01-A
BMS: with Smart BMS
Nominal Voltage: 48V
Nominal Capacity: 86Ah
Charge Current: 50A
Life Cycle: more than 2000 cycles
Communication: RS485&RS232
Weight: about 50Kg
Dimension: L835mm*W250mm*H180mm
Item: 15S200Ah-PC01-A
BMS: with Smart BMS
Nominal Voltage: 48V
Nominal Capacity: 200Ah
Charge Current: 50A
Discharge Current: 120A
Internal Resistance: less than 40ml
Life Cycle more than 2000 cycles
Communication: RS485&RS232
Weight: about 95.0Kg
Dimension : L800mm W350mm H230
Item: 15S134Ah-PC01-A BMS: with Smart BMS Nominal Voltage: 48V Nominal Capacity: 134ah Charge Current: 60A Discharge Current: 100A Internal Resistance: less than 30ml Life Cycle more than 1500 cycles Communication: RS485&RS232 Weight: about 60.0Kg Dimension : L740mm*W435mm*H150mm
Product Description
Item :12S100Ah-PC01-A
Nominal Voltage 36V
Nominal Capacity 100Ah
Charge Voltage 43.8V
Charge Current 50A
Discharge Current 100A
Discharge over current protection 150A
Internal Resistance 150m
Life Cycle 2000
Temperature Protection 55 C BMS
include BMS BMS Protection Short-circuit protection, over-charge protection, over-discharge protection, over-current protection, temperature protection and keep the battery .
Communication RS485&RS232
Dimension L800mm W250mm H250mm(Max)
Weight 31Kg 2Kg
Product Description
Item: 20S50Ah-PC01-A
Voltage: 60v
Capacity: 50ah
Discharge current: 50A
cell: 32700 cylinder, Grade A, real capacity, Life cycle is more than 2500 times
Communication: RS485, RS232, CAN
Product Description
Battery type 7S/24V/50Ah
Model no. 7S50Ah-PC02-A
Chemistry Ternary battery
Nominal Voltage 24V
Nominal Capacity 50Ah
Charge Voltage 29.4V
Charge Current 25A
Discharge Current 35A
Discharge over current protection 40A(5s),50A(100ms)Can be set
Discharge Cut-off Current 20V
Internal Resistance 80m
Life Cycle 800
Temperature Protection 55 C
BMS include BMS
Communication CAN
Dimension L335mm W190mm H110mm
Weight 11.0Kg 2.0Kg
Product Description
Item: 15S54Ah-PC01-A
Cell: 18650 cylinder, Grade A, real capacity, Life cycle is more than 2000 times
Voltage: 48v
Capacity: 54ah
Discharge current: 40A
Communication: RS485, RS232, CAN
Model NO. P12S52Ah-PACE02015
Nominal Voltage/Capacity 36V/52AH
Charge Voltage 38.4V
Current Max Charge Currentï¼?0.5C Max Discharge Currentï¼?1C
Temperature Chargeï¼?0ï½?55â?? Dischargeï¼?-20ï½?60â??
Communication CAN/RS485/RS232
Size 385*335*240MM
Weight 22�±2kg
Application Unmanned vehicles,golf carts
Model NO. P12S75Ah-PACE02016
Nominal Voltage/Capacity 36V/75AH
Charge Voltage 38.4V
Current Max Charge Current 0.5C Max Discharge Current 1C
Temperature Charge 0 55 Discharge -20 60
Communication CAN/RS485/RS232
Size 385*335*240MM
Weight 33 ±2kg
Application Unmanned vehicles,golf carts
24v 60Ah rechargeable lithium batteries with smart BMS for robots
charge current: 60A or custom
discharge current: 60A or custom
weight: 16.0Kg ±2.0Kg
size: L310mm*W220mm*H220mm or custom
communication protocal: RS232, RS485 or custom
48v 100Ah lithium battery pack for AGV
charge current: 60A
discharge current: 80A
size: L570mm*W300mm*H220mm
weight: 50kg
communication protocal: RS485, RS232, CAN
Item: 15S63Ah-PC01-A
BMS: with Smart BMS
Nominal Voltage: 48V
Nominal Capacity: 63Ah
Charge Current: 40A
Discharge Current: 40A
Internal Resistance: 30m
Life Cycle: 2000 cycles
Communication: RS485&RS232
Weight: 28Kg±2Kg
Dimension: L400mm*W300mm*H240mm
Model NO. P4S100Ah-PACE02014
Nominal Voltage/Capacity 12V/105AH
Charge Voltage 14.6V
Current Max Charge Current 100A Max Discharge Current 100A
Temperature Charge 0 55 Discharge-20 60
Communication Nothing but welcome to custom
Size 333*176*217mm
Weight 22±2kg
Application Unmanned vehicles, UPS, marine energy storage, golf carts
Model NO.P4S50Ah-PACE02013
Nominal Voltage/Capacity 12V/50AH
Charge Voltage 14.6V
Current Max Charge Current 50A Max Discharge Current 50A
Temperature Charge:0 55 Discharge-20 60
Communication:Nothing but welcome to custom
Size IS 227*106*223mm
Weight 12 ±2kg
Application Unmanned vehicles, UPS, marine energy storage, golf carts
24v 20Ah lithium battery pack with smart BMS for robots
charge current: 20A or custom
discharge current: 40A or custom
weight: 3.0Kg±0.5Kg
size: L170mm*W142mm*H105mm or custom
communication protocal: CAN or custom
